Solid State Relay Single Phase DC to AC 40A
$20.00
| Weight | .116 kg |
|---|---|
| Dimensions | 5.8 × 3.2 × 4.5 cm |
Additional information
CG 40A SSR Single Phase DC Control AC 220V Relay To 3-32VDC SSR- solid state module relay
Input voltage 3-32VDC
Output voltage 24-480VDC.
Current & Frequency:40a,50/60Hz.
Total size (approximate):58 x 45 x 32mm/2.3″ x 1.8″ x 1.26″ (l*w*t)
Net weight:116g
Material:metal, plastic, electronic parts
SSR Application: with a switch no spark, no noise,high switching speed,anti-corrosion,moisture-proof,anti-vibration,long life.high reliability,electromagnetic compatibility
and other characteristics.
Solid state relay ideal for automatic process control application, a must component for
temperature controller and other machinery control system.
Single Phase Solid State Relay with LED indicator
DC to AC/Input 3-32VDC To Output 24-480VAC /Maximum Current 40A
SSR series solid state relays (screw terminal connection) are of high strength, impact resistance and strong vibration resistance, with low requirement for input current. They can be easily connected with digital control circuits of computers. . They are updated products of AC and DC contactors. They are specially designed for harsh environments with corrosion, humidity or light-proof/explosion-proof requirements and frequent turn-on/off requirements.
WEIGHT: 28g
DIMENSIONS: 57.4mm x 28mm x 44.8mm
CG 40A SSR Single Phase DC Control AC 220V Relay To 3-32VDC SSR- solid state module relay
Input voltage 3-32VDC
Output voltage 24-480VDC.
Current & Frequency:40a,50/60Hz.
Total size (approximate):58 x 45 x 32mm/2.3″ x 1.8″ x 1.26″ (l*w*t)
Net weight:116g
Material:metal, plastic, electronic parts
SSR Application: with a switch no spark, no noise,high switching speed,anti-corrosion,moisture-proof,anti-vibration,long life.high reliability,electromagnetic compatibility
and other characteristics.
Solid state relay ideal for automatic process control application, a must component for
temperature controller and other machinery control system.
40A DA Single Phase DC Control AC Heat Sink 220V Relay To 3-32VDC SSR-10DA 25DA 40DA Plastic Cover Solid State Relay
Model SSR-40DA
Control Voltage 3-32VDC
Min Control Current 5mA
Max Control Current 25mA
Load Voltage 24-480VAC
Load Current 40A
Insulation Resistance 1000M Ohm/500VDC
Off Leakage Current <=2mA
On Voltage <=1.5V
On-off-Time <=10ms
Ambient Temperature -20~+75℃
Mouting Method Screw fixed
Relative Humidity ≤95%(Non-condensing)
Dimensions 57.4×44.8×32mm
Weight ≤135g
Manufacturer’s Warranty Applies.
